Big Sale! Baofeng UV-860 Pofung UV860 U/V Dual-Band Radio
Baofeng New UV-860 Two Way Radio 136-174/400-520Mhz Pofung bf-uv860 Ham cb Radio Walkie Talkie
Baofeng UV-860:
The transcevier is a micro-miniature multiband
FM transceiver with extensive receive frequency coverage,
It providing local-area two-way amateur communications along with unmatched monitoring capability
VHF/ UHF DUAL-BAND TWO WAY RADIO
Frequency Range: 136-174 / 400-520MHz
Dual-Band Display, Dual Freq. Display, Dual-Standby
Output Power: 8Watts
128 Channels
50 CTCSS and 104 CDCSS
Built-in VOX Function
1750Hz Brust Tone
FM Radio (65.0MHz-108.0MHz)
LED Flashlight
Large LCD Display
Hight /Low RF Power Switchable
25KHz/12.5KHz Switchable
Emergency Alert
Low Battery Alert
Battery Saver
Time-out Timer
Keypad Lock
Monitor Channel
Channel Step: 2.5/5/6.25/10/12.5/25KHz
ROGER SE
Dual band, dual display, dual standby A/B band independent operation
128 groups channels storage Shortcut menu operation mode
VFO & Memory channels scan Emergency Alarm
Tri-color background light selectable 0~9 grades VOX selectable
PTT & ANI ID FM radio and 25 stations storage
Voice companding CTCSS/DCS
PC programmable
Wide/Narrow Band(25kHz/12.5kHz) Transmitter time-out timer(TOT)
High/Low TX power selectable Busy channel lock-out(BCLO)
Item number UV-860
General
Frequency Range 65-108MHz(FM Receive only)
136-174MHZ and 400-520HZ (TX/RX)
Channel No. 128
Frequency Stability ±2.5ppm
Antenna High gain DualBand antenna
Antenna Impedance 50?
Operating Voltage DC 7.4V
Mode of operation Simple or semi-duplex
Dimension(W x H x D) 100 x 52 x 32 mm
Weight 250g(including battery, antenna)
Transmitter
Output power 8W
Modulation Mode 16k?F3E / 11k?F3E
Maximum deviation <5kHz(Wide) / <2.5kHz(Narrow)
Spurious Radiation <7?W
Adjacent Ch. power ?-65dB(Wide) / ?-60dB(Narrow)
Pre-emphasis characteristics 6dB
Current ?1.6A(5W)
CTCSS/DCS deviation 0.5±0.1kHz(Wide) / 0.3±0.1kHz(Narrow)
Intermediation sensitivity 8-12mv
Intermediation distortion <10%
Packing include:
1x Baofeng Dualband Radio 136-174MHz+400-520MHz
1x Dualband Antenna
1x Li-ion Battery
1x Charger with Adaptor (US. Or EU)
1x Belt clip
1x English User manual
1x Hand strip
1x Free earpiece
