AnyTone AT-D878S AES 256 GPS UHF 400-480MHz Single Band Digital/Analog Handheld DMR Walkie Talkie

$207.17$245.55

& Free Shipping
Guaranteed Safe Checkout

AnyTone UHF 400-480MHz Single Band Walkie Talkie

AnyTone AT-D878S AES 256 Digital/Analog Two-Way Radio GPS DMR Portable Transceiver

Frequency range:
66-88MHz;136-174MHz; 220~260MHz;
350~400MHz; 400~480MHz(EXP 400-520MHz)


Functions:
#True-2-slot: Provide 2-slot communication which allows for 2 talk paths on 1 frequency; ETSI DMR Tier I and II compliant
#Power:10W turbo/5W/2.5W/0.5W
#Auto-senses digital or analog reception
#4000 channels + VFO; 200,000Contacts
#Display: 1.77 inch TFT color LCD, dual display; dual standby; dual PA
#Bandwidth: 12.5K/25K (Analog); 12.5K (DMR)
#Fixed and defined CTCSS/DCS encode and decode
#DTMF/2TONE/5TONE encode and decode
#Four different Tone-pluse frequencies
#Individual/Group/All call
#Support Contact Manager
#Display the Caller ID and name
#Icon indicator or Voice prompt when connecting with repeater
#SMS via keyboard, One touch call/text
#Zone selection; Ranging function between radios with GPS
#ANI function and PTT ID; VOX; Digital Recording and Play
#Roaming function; Talker alias function
#IP connect to Motorola Repeater
#Emergency alarm (with GPS data transmission)
#Either Voice Recording 500 hours(optional) or BT (optional)
#GPS (optional)
#AES256 Digital encrytion
#Earphone: KENWOOD connector; Waterproof: IP54
#Battery: 3100mAh Li-ion thick battery 2100mAh Polymer filmy battery(optional)
Specification
General
Frequency Range
UHF radio: 400-480MHz VHF radio: 136-174MHz
Channel Capacity
4000 channels
Channel Spacing
25KHz (Wide Band) ,12.5KHz (Narrow Band)
Phase-locked Step
5KHz, 6.25KHz
Operating Voltage
7.4V DC ±20% /(2100mAh/3100mAh)
Frequency Stability
±2.5ppm
Operating Temperature
-20℃~ +55℃
Size
129×61×39mm (with battery pack)
Weight
282g (with battery pack, antenna)
Receiving Part
Wide band
Narrow band
Sensitivity(12dB SINAD)
≤0.25μV
≤0.35μV
Digital Sensitivity
0.3uV/-117.4dBm (BER 5%)
0.7uV/-110dBm (BER 1%)
Adjacent Channel Selectivity
≥70dB
≥60dB
Spurious Emission
≤-57dB
≤-57dB
Spurious Rejection
≥70dB
≥70dB
Blocking
84db
Hum & Noise
≥45dB
≥40dB
Audio Distortion
≤5%
Audio Power Output
1000mW/16Ω
Transmitting Part
Wide band
Narrow band
Power Output
UHF radio: 9/5/2.5/1W
VHF radio: 10/5/2.5/1W
Modulation
±5.0KHz@25KHz
±2.5KHz@12.5KHz
Adjacent Channel Power
≥70dB
≥60dB
Hum & Noise
≥40dB
≥36dB
Spurious Emission
≤-36dBm
≤-36dBm
4FSK Digital Modulation
12.5KHz(data)7K60FXD
12.5KHz(data+voice)7K60FXE
Audio Distortion
≤5%
Error rate
≤3%

Weight 1.2 kg
Dimensions 300 × 400 × 150 mm
Optional

AT-D878S, AT-D878S-B-Mic, AT-D878S-Battery, AT-D878S-Mic
