Features:
1) Output : 5W(H)/4W(M)/1W(L)
2) Frequency Range: 136.00-174.00 MHz
400.00-520.00MHz
3) IP57 waterproof and dustproof (Not diving)
4) High &Low Power Switchover
5) Battery Saving
6) VOX Function
7) Wide/Narrow Band Selection
8) Auto-Back Light
9) Dual Band Standby
10) Time-out Timer (TOT)
11) 50 CTCSS and 104 DCS Codes
12) Voice Prompt
13) ANI Code
14) PC or Manual Program
15) DTMF Code
16) PTT-ID
17) ATUO Keypad Lock
18) Busy Channel Lock Function
19) Dual Band, Dual Display and Dual Standby
20) Emergency Alarm
21) Priory Scanning Function
22) Relay Forwarding Confirmed (1750 HZ)
23) Low Battery Warning
24) U/V Cross Band Dual Watch
| Frequency Range: | 65MHz – 108MHz(Only commercial FM radio reception)
VHF:136MHz-174MHz (Rx/Tx) UHF:400MHz-520MHz(Rx/Tx) |
| Memory Channel | Up to 128 channels |
| Frequency Stability | 2.5ppm |
| Frequency step | 2.5kHz/5kHz/6.25Khz/10 Khz/12.5 Khz/20 Khz/25 Khz |
| Antenna Impedance | 50 Ω |
| Operating Temperature | -20 ℃ to +60℃ |
| Supply voltage | Rechargeable Lithium mAh 7.4V.1800 |
| Combination in standby | 380mA |
| Combination in transmission | ≤1.4A |
| Mode of operation | Simplex or semi-duplex |
| Duty cycle | 03/03/54 min.(Rx/Tx/Standby) |
| Dimension | 58mm x 110mm x 32mm |
| Weight | 150g (approximate) |
| RF Power | 5 W/1W |
| Type of modulation | FM |
| Emission class | 16KΦF3E/11KΦF3E(W/N) |
| Maximum deviation | ≤±5KHz/≤2.5KHz(W/N) |
| Spurious emissions | <-60 dB. |
| Receiver Sensitivity | ＜0.2 µ V (at 12dB SINAD) |
| Intermodulation | 60 dB. |
| Audio output | 1 W |
| Maximum deviation | ≤±5KHz/≤2.5KHz(W/N) |
| Spurious Radiation | <-60 dB. |
Each Set PACKAGE CONTAIN
1 x BF-A58 RADIO (136-174/ 400-520MHZ ) (Not for diving)
1 x 7.4V 1800mah Li-ion Battery Pack
1 x SMA-Female UHF Antenna
1 x Belt Clip
1 x ENG Manual
1 x Desktop Charger ( 100V ~ 240V )+(2pin USA or 3pin UK or 2pin EURO or 2pin Australia)
1 x PTT Earpiece for free
