Handheld Small Pocket Size 2-ways Radio TYT TH-2R

49.00$

  • Single Band:  VHF 136-174MHz  or  UHF 400-470MHz
  • CH 128 , All channel scan and priority channel scan
  • Scan types :Carrier, time and search
  • Busy channel lock: carrier/QT/DQT
  • VOX sensitivity:0-9 levels adjustable
VHF 136-174MHz
VHF 136-174MHz
UHF 400-470MHz
UHF 400-470MHz
Clear
SKU: 190084 Category:

Description

TYT TH-2R Two Way Radio

Main Functions:

1) CH 128 , All channel scan and priority channel scan
2) Scan types :Carrier, time and search
3) Busy channel lock: carrier/QT/DQT
4) VOX sensitivity:0-9 levels adjustable
5) Transmitter power:High power and low power switchable
6) Squelch opening threshold: Receive field intensity should accurate (use the sq level to show the intensity)
7) Led backlight: On/off/automatic
8) Beep set: Beep on/off
9) Keypad lock function: Manual/auto optional
10) Transmit limited: off-270 optional
11) Offset set:0-xxmhz optional (confirm the max offset according to the band after adjusting)
12) CTCSS and DCS setting
1. Receive only
2. Transmit only
3. 50 CTCSS and 104 DCS
13) +/-offset:+/-frequency optional
14) Offset step optional:12.5k/25k
15) Use Dot Segment to display on LCD
16) Select the LED/emergency call by programming software
17) Volume control knob to turn on/off the power
18) PC programming and store channel
19) Can use car charger
20) DC 3.7V single li-ion battery compatible with mobile phone battery
21) MINI compact size 84*48*25 cm
22) Output power:  2w
23) With most competitive price
24) CHANNEL STEP : 6.25khz/12.5khz/25khz/50khz/100khz

Technical parameters

Item number TH-2R
General
Frequency Range VHF 136-174MHz or UHF 400-470MHz



Channel No. 108
Antenna High gain antenna
Antenna Impedance 50Ω
Operating Voltage DC 3.6V(Rechargeable Li-ion battery)
Mode of operation Simplex
Dimensions(W×H×D) 84x48x26mm
Transmitter
Output power ≤2.5W(H)   ≤0.8W(L)
Modulation Mode 16kΦF3E/ 11kΦF3E
Maximum deviation <5kHz/<2.5KHZ
Spurious Radiation <7μW
Adjacent Ch. power ≥65dB/≥60db
Pre-emphasis characteristics 6db
Current ≤1.5A
CTCSS/DCS deviation 0.5kHZ+/-.01kHZ  03kHZ+/-0.1kHZ
Intermediation sensitivity 8-12mv
Intermediation distortion <10%
 Receiver
RF Sensitivity -122dbm(12db SINAD)
Audio power >0.5W
Audio Distortion ≤10%
Intermediation ≥60dB ≥55db
Selectivity ≥65dB ≥60db
Spurious Rejection ≥65db



Each Set Package Contain:

  • 1 x TH-2R Radio
  • 1 x 3.7V 1300mah Li-ion Battery
  • 1 x Antenna.
  • 1 x Belt Clip.
  • 1 x ENG Manual
  • 1 x DeskTop Charger with Cable  /PSU  (Provide PSU plug for your Country)
  • 1 x WRIST STRAP





Additional information

Weight 0.8 kg
Dimensions 200 × 180 × 60 mm
Frequency Range

VHF 136-174MHz, UHF 400-470MHz
