Mini Tri-band Mobile CB Radio QYT KT-8900R

KT-8900R is a mini size mobile radio, with tri-band, dual display, dual standby and dual track features, with compact and fashionable design, provides wide communication range and superb clear audio quality; Multiple back light colors selectale so as to recognize different working status easily; Power supplied by battery eliminator, with repeater function, easy installation & operation; KT-8900R is small size, easy to carry, reliable, durable and cost-effective, which will well meet your demand!

Functional Features:

Ø  VVU Tri-band Mobile Radio

Ø  Tri-band, Dual Display, Dual Standby & Dual Track

Ø  Mini Size, Power Supply: Battery Eliminator

Ø  With Repeater Function

Ø  Frequency Range Manual Setting

Ø  Software Password Setting

Ø  Remote Stun. Remote Kill & Remote Revive

Ø  DTMF, 2 Tone & 5 Tone

Ø  With Cooling Fan & External Audio Socket

Ø  Scrambler Function (Optional)

Item number	KT-8900R
General
Frequency Range	VHF:136-174MHz VHF:240-260MHz UHF:400-480MHz
Number of Channel	200
Channel Spacing	25KHz 20K 12.5
Phase lock step	2.5KHz、5KHz、6.25 KHz、10 KHz、12.5 KHz、15 KHz、25 KHz
Working Voltage	13.8V DC±15%
Squelch way	CTCSS/DCS/5Tone/2Tone/DTMF
Frequency Stability	±2.5ppm
Operating Temperature	-20~+60
Dimension(W x H x D)	98(W) x 35(H) x 118(D)mm
Weight	408g



Transmitter
	Broadband	Narrow band
Output power	25W（VHF）20W(UHF)
Modulation Mode	16KΦF3E	11KΦF3E
Channel Power	≥70dB	≥60B
Signal to noise ratio	≥40dB	≥36dB
Parasitic harmonic	≥60dB	≥60dB
Audio response	+1~ -3dB(0.3~3KHz)	+1~ -3dB(0.3~2.55KHz)
Audio distortion	≤5%



Receiver
	Broadband	Narrow band
Sensitivity	≤ 0.25μV	≤ 0.35μV
Channel choice	≥70dB	≥60dB
Intermodulation	≥65dB	≥60dB
Spurious Rejection	≥70dB	≥70dB
Audio response	+1~ -3dB(0.3~3KHz)	+1~ -3dB(0.3~2.55KHz)
Signal to noise ratio	≥45dB	≥40dB
Audio distortion	≤5%
Audio output power	≥2W@10%

EACH UNIT PACKAGE CONTAIN

1 x QYT KT-8900R

1 x Microphone

1 x Car Power Cable

1 x Fuse

1 x Mounting bracket

1 x Screw

1 x User”s Manual

1 x USB Programming Cable FOR QYT KT-8900R
