Baofeng DM-8HX Digital 2-ways Radio Walkie Talkie DMR Analog Dual Band UHF/VHF 5W 3800 mAh

Original price was: 80.00$.Current price is: 69.00$.

& Free Shipping
Guaranteed Safe Checkout

Are you tired of the always noise in the walkie talkie calls?

Here digital radio DM-8HX comes without any noise on the air. It great Helps your connection between you and your family or friends during the travel, fishing, hunting, farm work, off-roading and so on.

Are you tired of the low battery problem during the long trip two way radio talks?

Here digital radio DM-8HX built in 3800mAh high density battery. Standby time more than 40hours. Moreover, DM-8HX 25% battery saving compared to the analog radios.

Do you want to try high-tech digital radios while hate the boring thick user manual?

Here digital radio DM-8HX is as easy to use(even no need to reading the user manual) as the baofeng uv-5r. This simplex DMR radio decent for basic usage.

Do you want to use the digital radios while not missing the calls from your friends who are using the analogue radios ?

Here digital radio DM-8HX can satisfy you. Even though maybe part of your friends are using the analogue radios, some other part of your friends are using the DMR Tier I radios, you will not miss any of the calls from all the friends.

Do you want to buy digital radios while the cost too high for your budget?

Here Baofeng DM-8HX is only 1/2 cost of the market other brand digital radios. Moreover, the program cable, microphone speaker and all the other accessories for DM-8HX are the same with UV-5R’s. That will help save a lot of your money.



General Specifications

Note:                                     DM-8HX doesn’t support Time solt 2

Frequency range:                VHF/UHF 136-174/400-480Mhz

High/ Low Power Settings:   5W/1W

Storage Channel:                  128

Stepped frequency : 2.5/6.25/10/12/5/20/25KHZ

Operating voltage : DC 7.4V

Frequency stability :              ±1.5ppm

Operating temperature:       -20℃ ~ +50℃

Battery capacity:           3800 mAh

Antenna impedance : 50Ω

Antenna :                             21CM Dual Band Antenna

Stepped Frequency Selection : 8-Level

supports Mode : Digital & Analogue Mode

Volume:                                 110x58x32mm (without antenna)



Transmitting

Output power:                                               5W/1W

Modulation(wideband/narrowband) Analog:  16K¢F3E/11K¢F3E

Digital :                                                        4FSK

FSK allowable error:                                      rate ≤3%

Spurious power:                                             ≤ 7.5 uW

Adjacent channel power:                               ≤ -65dB / ≤ -60dB

Signal to noise ratio:                                       ≥-45dB / ≥ -40dB

(wideband/narrowband)

CTCSS/DCS frequency deviation:                  0.7±0.1KHZ/0.4±0.1KHZ

wideband /narrowband

Modulation sensitivity:                                     8-12 mV

Transmitting current:                                      ≤ 1.5A



Receiving

Analog sensitivity : -122dBm(12dB SINAD)

Digital sensitivity : -120dBm(BER≤5% )

Audio power  :                                                   1W

Audio distortion:                                               < 10%

Intermodulation (wideband/narrowband):         ≥62dB / ≥ 58dB

Adjacent channel selectivity : ≥65dB / ≥ 60dB

Receiving current : ≤ 380mA

Package list
1 x DM-8H DMR Radio
1 x Antenna
1 x Headset
1 x 3800 mAh Battery
1 x Desktop Charger
1 x Power Adaptor
1 x Belt Clip
1 x Hand Strap
1 x Manual
Weight 1 kg
Dimensions 260 × 200 × 90 mm
