Walkie Talkie Baofeng DM-1801 Updated Dual Band Digital Radio

Walkie Talkie Baofeng DM-1801 Updated Dual Band Digital Radio

Name: Walkie Talkie Baofeng DM-1801 Updated Dual Band Digital Radio
SKU: 1005004726808864
Availability: OutOfStock

Price range: $74.63 through $110.76

& Free Shipping

Color

add 48cm antenna

add 771

add cable

add extra battery

add speaker mic

as pic show

car charger cable

only radio

usb charger cable

Clear

Guaranteed Safe Checkout

Walkie Talkie Baofeng DM-1801 Updated Dual Band Digital Radio DR-1801 Tier 1+2 Dual Time Slot Long Range 136-174 & 400-520MHz DMR Digital Radio

If you need programming software, please contact our customer service,we will provide free programming software and technical guidance.

★【About New Programming and Software】

The DR-1801 is upgraded from the DM-1801. In order to distinguish the old version, it adopts a new programming software, which is compatible with the PL-2303 programming cable, which easily solves the problem of the DMR digital two way radio programming. (If you need new programming software, please contact us)

★【Digital walkie talkie】

Baofeng DR-1801 digital walkie talkie with 1.44″ LCD color display, dual band 136-147/400-470mHz, 1024 channels, dual mode (digital, analog) and dual time slots – more channels for enhanced privacy. Analog and digital DMR Tier I and II, Perfectly compatible with Motorola and other DMR radio; high/low power settings

★【Connect the repeater】

The DR1801 can reach the highest output power levels for handheld devices, and it can also be used with repeaters, which will help it get stronger signals and reach longer distances.

★【SMS Receiving and Sending】

You can use our DMR walkie-talkie to send text messages to your friends, and also receive text messages from other DMR devices.

★【More keypad operations】

Channel names, TX & RX frequencies, VOX, channel number, tones, and etc. can all be programmed through the keypad. Users can also customize the top and side buttons for their favorite functions.

Specifications:

General
Frequency Range	VHF:136-174MHz, UHF:400-470MHz (Dual Band)
Memory Channel	1024
Operating Voltage	DC 7.4V
Frequency stability	±1.0ppm
Demission	1336232mm (no including the antenna)
Operating environment	-30℃-+60℃
Weight	Approach.274g(including the battery and antenna)
Transmitter
Output power	High:5W Low:1W
Adjacent channel power	≤65dB ≤60dB
Output consumption	Analog≤1.6A Digital≤0.9A
Audio response	+1~3dB
Standby current consumption	≤0.18A
Digital Protocol	ETSI-TS102 361-1,-2,-3
Modulation distortion	≤5%
Vocoder type	AMBE+2 TM
FM/FM modulation:	16K￠F3E,25KHz 141K￠F3E,20KHz 11K￠F3E,12.5KHz
4FSK/4FSK digital modulation	12.5KHz for data:7K60FXD 12.5KHz for data and voice:7K60FXE
Signal-to-noise(wide/narrow)	≥45dB,25KHz ≥40dB,12.5KHz
Antenna Port Spurious	9KHz-1GHz ≤-36dBm 1GHz-12.75GHz: ≤-30dBm
Receiver
Analog receive sensitivity	-122dBm (12dB SINAD)
Digital receive sensitivity	-122dBm (BER≤5%)
Audio power	1W
Audio distortion	<10%
Signal imitation	≥70dB
Audio response	+1~3dB
Receive current	≤380mA
Intermediation(wide/narrow)	≥62dB/≥58dB
Adjacent channel selectivity	≥65dB/≥60dB
PM noise	≥45dB,25KHz / ≥40dB,12.5KHz
