AnyTone AT-D878UVII Plus Two Way Radio DMR & Analog FM APRS GPS Bluetooth Recording 2G ROM Wireless HAM Radios Comunication
- The AnyTone AT878UVII plus radio is a VHF and UHF radio with both Digital DMR (Tier I and II) and Analog capabilities. All the features of the excellent Anytone 868 with the addition of Roaming & Analogue APRS support (Includes GPS as standard)
- Offering a total of 4,000 channels (Analog and Digital), 10,000 Digital Talk Groups, and up to 150,000 contacts, as well as multiple DMR ID numbers (Radio ID’s) for a single radio.
- This enables Moonraker to supply it preprogrammed with all UK DMR and analogue vhf/uhf repeaters
- Supplied with a 3300 mAh battery the radio will give a good working days performance.
The Anytone AT-D878UV is a talky for the DMR digital system (compatible with MOTOTRBO Tier 1 and 2), it is also analogue in FM. Unlike many other DMR equipment, the AT-D878UV offers real VFO function. With it, you can set the desired frequency and configure it as usual, instead of limiting yourself to accessing only pre-programmed memory channels. Of course, the Anytone D878UV also has memory channels, 4000 to be exact. But you do not need to depend on pre-programmed channels. Another difference with other DMR equipment is that it has the possibility to change most of its parameters (not all). Therefore, you do not have to depend on a PC to make any changes to the configuration. However, there are certain parameters, such as the DMR ID, which you can only use with the free PC program.
Features:
● Dual-mode ( Digital+Analog)
● 1.77 inch color TFT Screen
● 4000channels
● 10000Talk Groups with 500000 Digital contacts
● ETSI DMR Tier Ⅰ and Ⅱ Compliant
● Auto-senses digital or analog reception
● Ranging function between radios with GPS
● Roaming function
Specification:
General
Frequency Range | 144-148MHz (V) , 430-440MHz (U) |
Channel Capacity | 4000 channels |
Channel Spacing | 25KHz (Wide Band) 12.5KHz (Narrow Band) |
Phase-locked Step | 5KHz, 6.25KHz |
Operating Voltage | 7.4V DC ±20% (3100mAh) |
Frequency Stability | ±2.5ppm |
Operating Temperature | -20℃~ +55℃ |
Size | 129×61×42mm (with battery pack) |
Weight | 293g (with battery pack) |
Power Output | VHF: 7/5/2.5/0.2W, UHF: 6/5/2.5/0.2W |
Modulation limit | ±5.0KHz@25KHz (Wide Band); ±2.5KHz@12.5KHz (Narrow Band) |
Adjacent Channel Power | ≥70dB (Wide Band); ≥60dB (Narrow Band) |
Hum & Noise | ≥40dB (Wide Band); ≥36dB (Narrow Band) |
Spurious Emission | ≤-36dB (Wide Band); ≤-36dB (Narrow Band) |
4FSK Digital Modulation | 12.5KHz(data)7K60FXD ; 12.5KHz(data+voice)7K60FXE |
Audio Distortion | ≤5% |
Error rate | ≤3% |
Sensitivity (12dB SINAD) | ≤0.25μV (Wide Band) 0.3uV/-117.4dBm (BER 5%) |
Digital Sensitivity | 0.7uV/-110dBm (BER 1%) ≤0.35μV (Narrow Band) |
Adjacent Channel Selectivity | ≥70dB (Wide Band) ; ≥60dB (Narrow Band) |
Spurious Emission | ≤-57dB (Wide Band); ≤-57dB (Narrow Band) |
Spurious Rejection | ≥70dB (Wide Band); ≥70dB (Narrow Band) |
Blocking | 84db |
Hum & Noise | ≥45dB (Wide Band);≥40dB (Narrow Band) |
Audio Distortion | ≤5% |
Audio Power Output | 1000mW/16Ω |
Packing List:
1x AT878UVII plus Radio(2G ROM ) ,recording
1x SMA-Female High Gain Antenna
1x Li-lion Battery
1x Charger Base
1x Plug Adapter
1x Bluetooth PTT Finger Key
1x Belt Clip
1x Program Cable
1x User Manual
