Sale!

AnyTone AT-D578UV III Pro Tri-Band DMR/Analog Car Radio with Bluetooth GPS

506.00$

& Free Shipping

Out of stock

Guaranteed Safe Checkout

DMR AT-D578UV III Pro Anytone Pro GPS APRS PTT Bluetooth Car Radio Commercial Radio communicator AT 578 for truck taxi

Anytone AT-D578UV III PRO 50W DMR digital mobile Radio Tri-band Walkie Talkie with GPS APRS Bluetooth

Anytone DMR radio At-d578uv Dual Band GPS radio transmitter communicator for communication



  1. AnyTone AT-D578UV III Pro Tri-Band Amateur DMR/Analog Mobile with Bluetooth GPS
  2. Free programming cable, Software and user guide on the USB thumb drive
  3. AnyTone Tri-Band DMR/Analog Amateur ATD578UV III Pro Mobile Radio with GPS and Built-in Bluetooth!
  4. Dual RX simultaneously (Analog +DMR or Analog +Analog)
  5. Cross Band Repeater Function

Dual RX simultaneously (Analog +DMR or Analog +Analog)

Cross Band Repeater Function

(FCC ID: T4K-D578UV)

Bluetooth(Built-IN)

Roaming (Auto/Manual)

Repeater Check (Out-of-range checking for repeater)

Talker Alias (Send and Displays)

Analog and DMR APRS

Custom Standby background picture

Compatible with 868 and 878 Codeplug

Dual-mode (Digital+Analog)

Features:

• Working Mode: Full duplex on UU, UV, VV,VU. Dual RX(Analog+DMR or Analog+Analog)

• True-2-slot: Provide 2-slot communication which allows for 2 talk paths on 1 frequency; ETSI DMR Tier I and II compliant

• Power: VHF 60W/25W/10W; UHF 50W/25W/10W

• Auto-senses digital or analog reception

• 4000 channels + VFO; 10,000 Talk groups with 200,000 digital contacts

• Support Contact Manager

• Display: 1.77 inch TFT color LCD, dual display; dual PA; dual PTT

• Bandwidth: 12.5K/25K (Analog); 12.5K (DMR);

• Weather Alerts

• VOX Function; Digital Recording and Play

• DTMF/2TONE/5TONE encode and decode

• AES256 digital encryption; Zone selection

• SMS via keyboard

• Crossband repeater function

• Ranging function between radios with GPS

• Roaming function; Talker alias function

• Emergency alarm (with GPS data transmission)

• IP connect to  Repeater

• Duplexer Talk(Optional)

• Call interrupt(Optional)

Specification:

GENERAL
Frequency Range 136-174MHz (V) , 400-490MHz (U)
Channel Capacity 4000 channels
Channel Spacing 25KHz (Wide Band) 12.5KHz (Narrow Band)
Phase-locked Step 5KHz, 6.25KHz
Operating Voltage 13.8V DC ±20%
Frequency Stability ±2.0ppm
Operating Temperature -20℃~ +55℃
TRANSMITTER
Power Output VHF: 50/25/10/5W
UHF: 45/25/10/5W
Modulation limit ±5.0KHz 25KHz (Wide Band)    ±2.5KHz 12.5KHz (Narrow Band)
Adjacent Channel Power ≥70dB (Wide Band)
≥60dB (Narrow Band)
Hum & Noise ≥40dB (Wide Band)
≥36dB (Narrow Band)
Spurious Emission ≥70dBc (Wide Band)
≥70dBc (Narrow Band)
4FSK Digital Modulation 12.5KHz(data)7K60FXD
12.5KHz(data+voice)7K60FXE
Audio Distortion ≤5%
Error rate ≤3%
RECEIVER
Sensitivity (12dB SINAD) ≤0.25μV (Wide Band)
≤0.35μV (Narrow Band)
Digital Sensitivity 0.3uV/-117.4dBm (BER 5%)
0.7uV/-110dBm (BER 1%)
Adjacent Channel Digital Sensitivity Selectivity ≥70dB (Wide Band)
≥60dB (Narrow Band)
Spurious Emission ≤-57dB (Wide Band)
≤-57dB (Narrow Band)
Spurious Rejection ≥70dB (Wide Band)
≥70dB (Narrow Band)
Blocking 84db
Hum & Noise ≥45dB (Wide Band)
≥40dB (Narrow Band)
Audio Distortion ≤5%
Audio Power Output ≥2W



Standard Accessories:

1 x AnyTone AT-D578UV III Pro Tri-Band Mobile Radio

1 x Speaker Microphone

1 x Mobile Mounting Bracket

1 x DC Power Cable with Fuse Holder

1 x USB Programming Cable

1 x Screws

1 x USER Manual

DMR AT-D578UV III Pro Anytone Pro GPS APRS PTT Bluetooth Car Radio Commercial Radio communicator AT 578 for truck taxiDMR AT-D578UV III Pro Anytone Pro GPS APRS PTT Bluetooth Car Radio Commercial Radio communicator AT 578 for truck taxiDMR AT-D578UV III Pro Anytone Pro GPS APRS PTT Bluetooth Car Radio Commercial Radio communicator AT 578 for truck taxiDMR AT-D578UV III Pro Anytone Pro GPS APRS PTT Bluetooth Car Radio Commercial Radio communicator AT 578 for truck taxiDMR AT-D578UV III Pro Anytone Pro GPS APRS PTT Bluetooth Car Radio Commercial Radio communicator AT 578 for truck taxiDMR AT-D578UV III Pro Anytone Pro GPS APRS PTT Bluetooth Car Radio Commercial Radio communicator AT 578 for truck taxiDMR AT-D578UV III Pro Anytone Pro GPS APRS PTT Bluetooth Car Radio Commercial Radio communicator AT 578 for truck taxiDMR AT-D578UV III Pro Anytone Pro GPS APRS PTT Bluetooth Car Radio Commercial Radio communicator AT 578 for truck taxiDMR AT-D578UV III Pro Anytone Pro GPS APRS PTT Bluetooth Car Radio Commercial Radio communicator AT 578 for truck taxi

Weight 0.6 kg
Dimensions 400 × 400 × 100 mm
Opational

Z115 PTT K plug, Throat mic K plug, Z115 midland plug, Midland Earpiece
