Feature
Output Power: 50 Watts(VHF )/40 Watts (UHF)
Frequency Range:VHF 136 – 174 MHz /UHF 400 – 490 MHz
CTCSS/DCS/DTMF/2 Tone/5 Tone decode and encode
ANI function (DTMF/ANI,5-Tone/ANI)PTT ID
FCC Certified
True Dual Band Receive
200 Memory Channels
APO Power Management
Selectable Three Color Backlight
Dual Display V/U U/V V/V U/U
Scrambler function(optional)
DTMF Microphone
Main Function
01.Menu setting
02. Work by repeater station
03. Auto repeater offset frequency
04. Remote Kill/stun/activate/revive
05. Wide/Narrow band setting
06. Channel Name editing
07. CTCSS/DCS Setting& Scanning
08. High/Mid/Low Power selectable
09. Voice compander
10. Repeater offset shift
11. DTMF/2 ton/5 tone
12. Talk around
13. Voice prompt
14. Auto Power off
15. Scrambler
16. Emergency Alarm
17. COMP function
18. Scan function
19. 1750Hz tone
20. ANI ID
21. Microphone lock/ Mic programmable menu
22. Call keypad
23. 200 channels
Specification :
| Frequency Range | VHF: 136-174MHz; UHF: 400~490MHz |
|
| Number of Channels | 200 programmable memorized channels,channels can be marked with letter and digits. | |
| Channel Spacing | 25K (Wide Band) 20K(Middle Band) 12.5K (Narrow band) | |
| Phase-locked Step | 5KHz,6.25KHz,8.33KHz,10KHz,12.5KHz,15KHz, 20KHz,25KHz,30KHz,50KHz | |
| Operating Voltage | 13.8V DC ±15% | |
| Squelch | Carrier/CTCSS/DCS/5Tone/2Tone/DTMF | |
| Frequency Stability | ±2.5ppm | |
| Operating Temperature | -20°C~+60°C | |
| Dimensions(WxHxD) | 145 (W) x 47 (H) x 190 (L)mm | |
| Weight | about 1.2Kg for radio
Power 50W/25W/10W/5W VHF;40W/25W/10W/5W UHF |
|
| Receiver (ETSI EN 300 086 standard testing ) | ||
| Wide band | Narrow band | |
| Sensitivity (12dB Sinad) | ≤0.25μV | ≤0.35μV |
| Adjacent Channel Selectivity | ≥70dB | |
| Each Set PACKAGE CONTAIN |
- 1x ANYTONE AT-588UV Dual Band Mobile Radio
- 1x Microphone
- 1x Mobile Mounting Bracket
- 1x DC Power Cable
- 1x Screws, S-Washer,Spare Fuses pack
- 1x English Manual
Free send 1 x Programming Cable
