Sale!
,

25W Dual Band Mini Color Screen Mobile Radio QYT KT-8900D

Original price was: 115.00$.Current price is: 83.00$.

& Free Shipping
Guaranteed Safe Checkout

UPGRADE Version of QYT KT-8900 Mini Size Mobile Radio:

– Dual Band with 4 Bands STANDBY in LARGE LCD

– WITH Cooling Fans for longer timer operation

– WITH AUDIO Connector for External Speaker

Specifications:

Item number QYT 8900D Mobile Radio
General
Frequency Range VHF:136-174MHz  UHF:400-480MHz
Number of Channel  200
Channel Spacing 25KHz 20K 12.5
Phase lock step 5KHz, 6.25 KHz, 10 KHz ,12.5 KHz, 15 KHz, 25 KHz
Working Voltage 13.8V DC±15%
Squelch way CTCSS/DCS/5Tone/2Tone/DTMF
Frequency Stability ±2.5ppm
Operating Temperature -20~+60
Dimension(W x H x D) 98(W) x 35(H) x 118(D)mm
Weight 408g



Receiver
Broadband Narrow band
Sensitivity ≤ 0.25μV ≤ 0.35μV
Channel choice ≥70dB ≥60dB
Intermodulation ≥65dB ≥60dB
Spurious Rejection ≥70dB ≥70dB
Audio response +1~ -3dB(0.3~3KHz) +1~ -3dB(0.3~2.55KHz)
Signal to noise ratio ≥45dB ≥40dB
Audio distortion ≤5%
Audio output power ≥2W@10%
Transmitter
Broadband Narrow band
Output power 25W/20W(VHF/UHF)
Modulation Mode 16KΦF3E 11KΦF3E
Channel Power ≥70dB ≥60B
Signal to noise ratio ≥40dB ≥36dB
Parasitic harmonic ≥60dB ≥60dB
Audio response +1~ -3dB(0.3~3KHz) +1~ -3dB(0.3~2.55KHz)
Audio distortion ≤5%

STANDARD PACKAGE INCLUDES:

1 x QYT KT-8900D Radio

1 x Speaker Microphone with Keypad

1 x DC Power Cable (with Cigarette Lighter)

1 x Mounting Bracket

1 x Mounting Screws Kit

1 x English User’s manual

1 x Programming Cable



Weight 1.6 kg
Dimensions 400 × 300 × 90 mm
