TYT MD-680 Handheld UHF VHF DMR Ham Waterproof Digtial Two Way Radio

Sale!

TYT MD-680 Handheld UHF VHF DMR Ham Waterproof Digtial Two Way Radio

$150.00 $90.00

1. Frequency Range: UHF400~480MHz / VHF 136-174MHz
2. Memory Channel: 32
3. Battery Capacity: 2200Mah supplies longer working time, analog15hrs and digital25hrs
4. Channel Spacing: 12.5KHz
5. Output Power: Low:1W High:10W
6. Rate Audio Power: 1W
7. Audio Response: +1dB~-3dB
8. Voltage: 7.2V DC
9. Digital Procotol: ETSI TS102 361-1 -1 -3
Clear
SKU: 190007 Category:

Description

TYT MD-680 UHF VHF DMR Digtial Ham Radio 10W Power IP67 Walkie Talkie Transceiver

Features:

1. It applies advanced TDMA digital technology, a digital radio that reserves analog mode for flexible uses
2. Up to 10W high power two-way radio, featuring further communication range
3. 2200Mah large capacity battery lasts for longer working time: Analog 15hours, Digital 25hours
4. IP 67 water resistant level, durable and solid to work under complicated environments

Functions:

1. Frequency Range: UHF400~480MHz / VHF 136-174MHz
2. Memory Channel: 32
3. Battery Capacity: 2200Mah supplies longer working time, analog15hrs and digital25hrs
4. Channel Spacing: 12.5KHz
5. Output Power: Low:1W High:10W
6. Rate Audio Power: 1W
7. Audio Response: +1dB~-3dB
8. Voltage: 7.2V DC
9. Digital Procotol: ETSI TS102 361-1 -1 -3

Specifications:

General
Frequency Range         UHF: 400-480MHZ / VHF 136-174MHz
Channel Capacity        256
Channel Spacing          12.5KHz
Operating Temperature   -30~ +60
Operating Voltage       7.5V DC ±20%
Battery                        7.2V 2800mAH Li-ion
Frequency Stability     ±2.5 ppm
Dimension (with battery and antenna)   125mm *63mm*38mm
Weight (with battery and antenna)      243g
Transmitter
RF Power Output             10W
Frequency Modulation    16KφF3E/11KφF3E (Analog)   4FSK(Digital)
Antenna Impedance        50Ω
FM Modulation mode      12.5KHz:11K0F3E
4FSK Digital Mode          12.5KHZ:7K60FXD(data)/7K60FXE(data&voice)
Modulation maximum deviation           2.5KHz @ 12.5KHz
Modulation Distortion     < 5%
Nonactive Slot Power     -57dbm
Vocodec Type                  AMBE+2TM
Digital Protocol                Digital Protocol
Receiver
Analog Sensitivity             0.35μV / -116dBm(20dB SINDA)
                                            0.22μV / -120dBm(Type)
Digital Sensitivity              0.3μV / -117.4dBm(BER5%)
                                            0.22μV / -110dBm(BER1%)
Co-channel Rejection          ≥-12dB
Adjacent Channel Selectivity   TIA603C:65dB ETSI:60dB
Spurious Response Rejection    TIA603C:75dB ETSI:70dB
Rated Audio Output          1W
Audio response                   =1dB~-3dB
Rated Audio Distortion     <3%
Package Included:
1x TYT MD-680 DMR Digital 10W Two-way Radio
1x Antenna
1x Cradle Charger
1x Programming Cable
1x Belt Clip
1x User Manual
1x PTT Earpiece

Additional information

Weight N/A
Dimensions N/A
Frequency Range

UHF 400-480MHz, VHF 136-174MHz
